Image and Display:
- Projection System: 3LCD Technology, RGB liquid crystal shutter
- LCD Panel: 0.62 inch with C2 Fine
- Color Light Output: 4,000 Lumen (ISO), 2,000 Lumen (economy)
- White Light Output: 4,000 Lumen (ISO), 2,000 Lumen (economy)
- Resolution: 4K PRO-UHD
- Resolution Enhancement: 4K enhancement
- Aspect Ratio: 16:9
- Contrast Ratio: 2,500,000:1
- Colour Reproduction: Up to 1.07 billion colours
- HDR Support: HDR10, HLG
- Colour Video Processing: 10 Bits
- 2D Vertical Refresh Rate: 192 Hz – 240 Hz
Lamp and Lens:
- Light Source: Laser
- Laser Light Source Durability:
- 20,000 hours (High)
- 20,000 hours (Medium)
- 20,000 hours (Eco)
- Throw Ratio: 0.16 – 0.40:1
- Zoom: Digital, Factor: 1 – 2.5
- Projection Lens Zoom Ratio: 0.28 – 0.54:1
- Lens Shift: Manual – Vertical ± 7%
- Screen Size: 80 inches – 150 inches
- Projection Distance Wide: 0.3 m – 0.5 m (for a 150 inch screen)
- Projection Distance Tele: 0.3 m – 0.5 m (for a 60 inch screen)
- Projection Lens F Number: 1.8
- Projection Lens Focal Length: 2.3 mm
- Projection Lens Focus: Manual
Adjustments and Features:
- Keystone Correction: Auto vertical ± 30°, Manual horizontal ± 30°
- Digital Keystone Correction: Horizontal and Vertical
- Android TV: Yes
- Other Features:
- 4K enhancement
- Built-in speaker (20 Watt, Stereo)
- Chromecast
- Frame interpolation
- Quick Corner
- Sound by Yamaha
- Video Color Modes: Cinema, Dynamic, Natural, Vivid
General:
- Power Consumption:
- Normal Peak-mode: 350 Watt
- Eco Peak-Mode: 217 Watt
- Energy Saving Standby: 2 Watt
- Heat Dissipation: 1,139 BTU/hour (max)
- Supply Voltage: AC 100 V – 240 V, 50 Hz – 60 Hz
- Product Dimensions: 695 mm x 341 mm x 156 mm (WxDxH)
- Product Weight: 12.3 kg
- Noise Level:
- Normal: 32 dB (A)
- Economy: 19 dB (A)
- Supported Temperature:
- Operation: 5° C – 35° C
- Storage: -10° C – 60° C
- Supported Humidity:
- Operation: 20% – 80%
- Storage: 10% – 90%
- Warranty: Details not provided
Connectivity and Additional Features:
- Interfaces:
- USB 2.0-A (3x)
- USB 2.0 Type B (Service Only)
- Wireless LAN IEEE 802.11a/b/g/n/ac
- Jack plug out
- Bluetooth
- HDMI ARC
- HDMI (HDCP 2.3) (3x)
- Options: Air filter, Ceiling mount, Suspension adapter
- Room Type / Application: 4K Gaming, 4K Streaming, Home Cinema, Sports, Streaming, TV & Box sets
- Positioning: Ceiling Mounted, Desktop, TV Cabinet
- Colour: White
